| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | Sino Cable Gland Factory |
| Certification: | CE, ROHS, PAHS, REACH, SGS, IP68 |
| Model Number: | PG9~PG48 / M14x1.5~M63x1.5 |
| Minimum Order Quantity: | 100pcs |
| Price: | very competitive prices |
| Packaging Details: | standard export packing (special packing also available on request) |
| Delivery Time: | normally 8-10 days |
| Payment Terms: | T/T, L/C, Western union |
| Supply Ability: | 3000000pcs / month |
| Size: | Full Sizes | Protection Level: | IP68 |
|---|---|---|---|
| Material: | Nylon | Standard Colors: | Black RAL9005 (other Colors Also Available On Request) |
| Connection Thread Type: | PG Thread & Metric Thread | Quality Grade: | High Quality (8-15 Years Of Long Life For Indoor Application) |
| Main Advantages: | Extra Resistance To Pull-out |
How to use:
Mount gland to the pre-drilled panel hole and fix it on board with locknut, insert the cables through the rubber seal and then tighten up the sealing nut to hold cables in position, finally tighten the two clamping screws.
Descriptions:
| Brand name: | Sino Cable Gland Factory |
| Place of origin: | Zhejiang, China |
| Product name: | Nylon (Plastic) Cable Gland IP68 with Traction Relief / Strain Relief / Stress Relief |
| Sizes available: |
* PG9, PG11, PG13.5, PG16, PG21, PG29, PG36, PG42, PG48 |
| Raw material: | UL-approved new Polyamide 66, flammability 94V-2 for Locknut & Body (94V-0 material is optional) |
| Plastic spraying alloy for Sealing Nut with two clamping screws | |
| NBR or weatherproof EPDM rubber for Seal & O-ring | |
| Standard colors: | Black RAL9005, special colors can be customized according to customer's request |
| Certifications: | CE, ROHS, PAHS, REACH, SGS, IP68 |
| IP protection: | IP68 (when the cable diameter is within the clamping range and assemble the O-ring) |
| Thread lengths: | Short thread & long thread are available |
| Thread system: | PG: according to the standard DIN40430 & Metric: according to the standard EN60423 |
| Operation temp.: | Static:-40℃ to100℃, short-term:120℃. Dynamic:-20℃ to 80℃, short-term:100 ℃ |
| Quality grade: | High quality can last 8-12 years of long service life for indoor applications |
| OEM service: | Yes, available |
| Supply capability: | 2,000,000 pieces per month |
| Minimum quantity: | 100 pieces |
| Samples available: | Free samples available upon request |
| Delivery time: | Normally 8-10 days after confirmation of orders |
| Payment terms: | T/T in advance, Western Union, L/C at sight |
| Shipment terms: | EMS / TNT / DHL / UPS / FEDEX or FOB, CIF, C&F |
| Shipment ports: | Ningbo / Shanghai |
| Export packing: |
100 pieces / bag, 100pieces /color box, special packing can be customized as requested |
