| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | Yueqing Sino Cable Gland Factory |
| Certification: | CE, ROHS, PAHS, REACH, SGS, IP68 |
| Model Number: | PG & Metric Models |
| Minimum Order Quantity: | 1000pcs |
| Price: | Best prices from direct factory |
| Packaging Details: | standard packing: 100pcs/bag, 50pcs/bag, 20pcs/bag |
| Delivery Time: | 8-10 days |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 5000000pcs per month |
| Features: | Anti-aging, Insulation, Anti-corrosion, Anti-acid, Liquid Tight, Etc | Material: | UL-approved PA6, 94V-2 |
|---|---|---|---|
| Seal & O-ring: | NBR, EPDM, FKM Rubber | Colors: | Grey, Black, White, Red, Blue, Etc |
| Protection: | IP68 (assemble The O-ring On The Groove) | Product Name: | Extended Thread Cable Gland, Long Thread Cable Gland |
| Brand name: | Yueqing Sino Cable Gland Factory |
| Place of origin: | Zhejiang, China |
| Product name: | Cable Gland IP68 Plastic Synthetic Non-Metallic with Elongated PG or Metric Thread for Thick Enclosure |
| Sizes available: |
* PG7, PG9, PG11, PG13.5, PG16, PG21, PG29, PG36, PG42, PG48 * M10x1, M12x1.5, M14x1.5, M16x1.5, M18x1.5, M20x1.5, M22x1.5, M24x1.5, M25x1.5, M27x1.5, M30x1.5, M32x1.5, M36x1.5, M40x1.5, M50x1.5, M63x1.5, M75x2 |
| Raw material: | UL-approved new Polyamide 66, 94V-2 for Sealing Nut, Locknut & Body (94V-0 material is optional) |
| NBR or weatherproof EPDM rubber for Seal & Washer (O-ring) | |
| Standard colors: | Light-grey RAL7035, black RAL9005 (available in dark-grey RAL7001, blue RAL5012, orange RAL6018, red RAL3031, green RAL2004 & white RAL9010, such special colors can be customized according to customer's request) |
| Certifications: | CE, ROHS, PAHS, REACH, SGS, IP68 |
| IP protection: | IP68 (when the cable diameter is within the clamping range and assemble the Washer or O-ring) |
| Thread lengths: | Short thread & long thread are available |
| Thread system: | According to the standard DIN40430 |
| Operation temp.: | Static:-40℃ to100℃, short-term:120℃. Dynamic:-20℃ to 80℃, short-term:100 ℃ |
| Quality grade: | High quality can last 8-12 years of long service life for indoor applications (ordinary quality is available on request) |
| OEM service: | Yes, available |
| Supply capability: | 5,000,000 pieces per month |
| Minimum quantity: | 500 pieces |
| Samples available: | Free samples available upon request |
| Delivery time: | Normally 5-7 days after confirmation of orders |
| Payment terms: | T/T in advance, Western Union, L/C at sight |
| Shipment terms: | EMS / TNT / DHL / UPS / FEDEX / By sea / By air or as required |
| Export packing: | 100 pieces / bag, 100pieces /color box, special packing can be customized as requested |
