| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | Sino Cable Gland Factory or OEM |
| Certification: | CE, SGS, IP68, IP69K |
| Model Number: | PG7~PG21 |
| Minimum Order Quantity: | 100 pieces |
| Price: | direct sale prices from factory |
| Packaging Details: | standard packing (special packing is also available on request) |
| Delivery Time: | normally 14-20 days |
| Payment Terms: | T/T, L/C, Western union |
| Supply Ability: | 1,000,000 pieces per month |
| Product Name: | Stainless Steel Spiral Cable Glands | Material: | Stainless Steel AISI304 And AISI316 |
|---|---|---|---|
| Clamping Claw: | UL-approved PA66, 94V-2 | Sealing Parts: | Oil-resistant NBR (EPDM Also Available On Request) |
| Thread: | According To German Standard DIN 40430 | Waterproof Rate: | IP68 |
| Functions: | Protect Cables Against Excessive Bending To Avoid The Breakage |
SS304 / SS316 Stainless Steel Metallic PG Cable Glands IP68 with Spiral Protecting Spring
| Thread | Sealing Range | AG (mm) | Panel Mounting Hole (mm) | GL (mm) | H (mm) | d (mm) | Spanner (mm) | Packing (pieces/bag) | |
| Min. (mm) | Max. (mm) | ||||||||
| PG7 | 3 | 6.5 | 12.5 | 12.7 | 5 | 55 | 6.8 | 14 | 50 |
| PG7 | 2 | 5 | 12.5 | 12.7 | 5 | 55 | 6.8 | 14 | 50 |
| PG9 | 4 | 8 | 15.2 | 15.4 | 6 | 66 | 8.2 | 17 | 50 |
| PG9 | 2 | 6 | 15.2 | 15.4 | 6 | 66 | 8.2 | 17 | 50 |
| PG11 | 5 | 10 | 18.6 | 18.8 | 6 | 77 | 10.3 | 20 | 20 |
| PG11 | 3 | 7 | 18.6 | 18.8 | 6 | 77 | 10.3 | 20 | 20 |
| PG13.5 | 6 | 12 | 20.4 | 20.6 | 6.5 | 88 | 12.3 | 22 | 20 |
| PG13.5 | 5 | 9 | 20.4 | 20.6 | 6.5 | 88 | 12.3 | 22 | 20 |
| PG16 | 10 | 14 | 22.5 | 22.7 | 6.5 | 98 | 14.3 | 24 | 20 |
| PG16 | 7 | 12 | 22.5 | 22.7 | 6.5 | 98 | 14.3 | 24 | 20 |
| PG21 | 13 | 18 | 28.3 | 28.5 | 7 | 111 | 18.4 | 30 | 10 |
| PG21 | 9 | 16 | 28.3 | 28.5 | 7 | 111 | 18.4 | 30 | 10 |
