| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | Sino Cable Gland Factory or OEM |
| Certification: | CE, ROHS, PAHS, REACH, IP68, IP69K, Anti-UV |
| Model Number: | M12x1.5 ~ M75x2 |
| Minimum Order Quantity: | 500 pieces |
| Price: | at very competitive prices from direct factory |
| Packaging Details: | standard export packing (special packing also available on request) |
| Delivery Time: | normally 5-8 days |
| Payment Terms: | T/T, L/C, Western union |
| Supply Ability: | 3000000 pieces PE month |
| Features: | Weather Resistant & Liquid Tight, Resistant To Weak Acid & Alkaline, Corrosion-resistant, Anti-UV | Material: | UL-approved PA66, 94V-2 (94V-0 Is Optional) |
|---|---|---|---|
| Standard Colors: | Light-grey RAL7035, Black RAL9005 (other Colors Also Available On Request) | Models: | Full Models (M12 ~ M75) |
| Protection: | IP68 | Thread Standard: | According To The Standard EN60423 |
| Quality Grade: | High Quality (6-12 Years Of Long Life For Indoor Application) |
Polyamide polymer synthetic cable gland is a kind of mechanical cable entry device and can be constructed from metallic materials (mainly brass or stainless steel) or non-metallic materials (mainly polyamide, polymer or synthetic). They are used throughout a number of industries in conjunction with cable and wiring used in electrical instrumentation and automation systems.
Polyamide Polymer IP68 Waterproof Adjustable Metric Electrical Cable Glands with Sealing Washers (Gaskets) may be used as sealing and termination devices to ensure that the characteristics of the enclosure which the cable enters can be maintained adequately. Having the features of wide clamping range, high strain relief, waterproof protection and anti-vibration mechanism, they are popularly applicable for solar, wind, oil & gas, pumps, filters, fans, transducers, sensors, scales, flow meters, lighting, motors, encoders, power supplies, antennas, harnesses for pool & spa, car wash, dairy, food & beverage, pharmaceutical, petro, telecom, automotive, traffic, robotics, medical, packaging, automation, marine and many more industries.
| Brand name: | Sino Cable Gland Factory |
| Place of origin: | Zhejiang, China |
| Product name: | Polyamide Polymer IP68 Waterproof Adjustable Metric Electrical Cable Glands with Sealing Washers (Gaskets) |
| Sizes available: | M12, M16, M18, M20, M25, M32, M40, M50, M63, M75 |
| Raw material: | UL-Polyamide 66, 94V-2 for Nut, Locknut & Body (contact us for 94V-0 material) |
| Weatherproof EPDM rubber for Seal & Washer | |
| Standard colors: | Light-grey RAL7035, black RAL9005 (available in dark-grey RAL7001, blue RAL5012, orange RAL6018, red RAL3031, green RAL2004 & white RAL9010, such special colors can be customized according to customer's request) |
| Certifications: | CE, ROHS, PAHS, REACH, IP68, IP69K, UV |
| IP protection: | IP68 (when the cable diameter is within the clamping range and assemble the Washer) |
| Thread lengths: | Available in short thread and long thread |
| Thread system: | According to the standard EN60423 |
| Working temperature: |
Static: -40℃ to +100℃, short-term: +120℃ Dynamic: -20℃ to +80℃, short-term: 100℃ |
| Quality grade: | High quality can last 8-12 years of long service life for indoor applications & at least 5 years of long life for outdoor applications |
| OEM service: | Yes, available |
| Supply capability: | 3,000,000 pieces per month |
| Minimum quantity: | 500 pieces |
| Samples available: | Free samples are available upon request |
| Delivery time: | Normally 5-7 days after confirmation of orders |
| Payment terms: | T/T, Western Union, L/C at sight |
| Shipment terms: | Shipped by EMS / TNT / DHL / UPS / FEDEX, by sea / by air |
| Export packing: |
100 pieces per bag + 100 pieces per color box, special packing can be customized as requested |
