| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | Sino Cable Gland Factory |
| Certification: | CE, ROHS, PAHS, REACH, IP68, IP69K, UV, HF |
| Model Number: | NCG series |
| Minimum Order Quantity: | 500 pieces |
| Price: | most competitive prices from direct factory |
| Packaging Details: | standard packing (special packing is also available on request) |
| Delivery Time: | normally 5-8 days |
| Payment Terms: | T/T, L/C, Western union |
| Supply Ability: | 5,000,000 pieces each month |
| Features: | Resistant To Weather, Water, Weak Acid, Alkaline, Corrosion, Temperature And Ultraviolet Rays. | Model: | Complete Models |
|---|---|---|---|
| Protection Class: | IP68, IP69K | Plastic Parts: | UL-approved PA66, 94V-2 (optional 94V-0) |
| Rubber Parts: | Corrosion Resistant Silicone Rubber | Standard Colors: | Light-grey RAL7035, Black RAL9005 (other Colors Also Available On Request) |
| Thread Standard: | According To European Standard EN60423 | Quality Grade: | High Quality (6-12 Years Of Long Life For Indoor Application) |
| Brand name: | Sino Cable Gland Factory |
| Place of origin: | Zhejiang, China |
| Product name: | Electrical Cable Gland, Nylon 6, 20mm Metric Thread, M20x1.5, IP68/IP69K, UL94 V-2, para Cable Ø 6-12mm |
| Sizes: | M20x1,5 (Cable Ø 6-12mm & 10-14mm) |
| Materials: | plastic parts: UL-polyamide 66, 94V-2 (contact us for 94V-0 material) |
| sealing parts: Silicone rubber | |
| Colors: | grey RAL7035, black RAL9005, special colors are customizable according to customer's request) |
| Certifications: | CE, ROHS, PAHS, REACH, IP68, IP69K, UV, Halogen Free |
| IP protection: | IP68 / IP69K (when the cable diameter is within the clamping range and mount the O-ring) |
| Thread length: | available in standard thread or extralong thread |
| Thread system: | according to standard EN 60423 |
| Working temperature: | static: -40℃ to +100℃, short-term: +120℃. |
| Quality grade: | high quality version can last 8-12 years of long service life for indoor applications & at least 5 years of long life for outdoor applications |
| OEM services: | yes, available |
| Supply capability: | 5,000,000 pieces each month |
| Minimum quantity: | 500 pieces |
| Samples: | free samples are available upon request |
| Delivery time: | normally 5-8 days after confirmation of orders |
| Payment conditions: | T/T, Western Union, L/C at sight |
| Shipment terms: | shipped by courier like EMS / TNT / DHL / UPS / FEDEX or by sea or by air |
| Export packing: | 100 pieces per bag + 100 pieces per color box, |
