UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread

Basic Information
Place of Origin: Zhejiang, China
Brand Name: Sino Cable Gland Factory
Certification: CE, ROHS, PAHS, REACH, IP68, IP69K, UV, HF
Model Number: NCG series
Minimum Order Quantity: 1000 pieces
Price: most competitive prices from direct factory
Packaging Details: standard packing (special packing is also available on request)
Delivery Time: normally 5-8 days
Payment Terms: T/T, L/C, Western union
Supply Ability: 5,000,000 pieces each month
Detail Information
Features: Resistant To Weather, Water, Weak Acid, Alkaline, Corrosion, Temperature And Ultraviolet Rays. Model: Complete Models
Protection Class: IP68, IP69K Plastic Parts: UL-approved PA66, 94V-0
Rubber Parts: Corrosion Resistant Rubber Standard Colors: Light-grey RAL7035, Black RAL9005 (other Colors Also Available On Request)
Thread Standard: According To European Standard EN60423 Quality Grade: High Quality (6-12 Years Of Long Life For Indoor Application)
Product Name: UV Resistant Cable Glands, Solar Cable Glands

Product Description

Product Description:
UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread are a kind of mechanical cable entry device and can be constructed from metallic materials (mainly brass or stainless steel) or non-metallic materials (mainly polyamide, polymer, synthetic or PP). They are used throughout a number of industries in conjunction with cable and wiring used in electrical instrumentation and automation systems.

UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Threadmay be used as sealing and termination devices to ensure that the characteristics of the enclosure which the cable enters can be maintained adequately. Having the features of wide clamping range, high strain relief, waterproof protection and anti-vibration mechanism, they are popularly applicable for solar, wind, oil & gas, pumps, filters, fans, transducers, sensors, scales, flow meters, lighting, motors, encoders, power supplies, antennas, harnesses for pool & spa, car wash, dairy, food & beverage, pharmaceutical, petro, telecom, automotive, traffic, robotics, medical, packaging, automation, marine and many more industries.

Information:
Brand name:Sino Cable Gland Factory
Place of origin:Zhejiang, China
Product name:UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread
Sizes:

M12, M16, M18, M20, M22, M24, M25, M27, M28, M30, M32, M36, M40, M50, M63, M75

Materials:plastic parts: UL-polyamide 66, 94V-0
rubber parts: NBR, EPDM, Silicone, Viton rubber
Colors:black RAL9005, special colors are customizable according to customer's request)
Certifications:CE, ROHS, PAHS, REACH, IP68, IP69K, UV, Halogen Free
IP protection:IP68 / IP69K (when the cable diameter is within the clamping range and mount the O-ring)
Thread length:available in short thread & long thread
Thread system:according to standard EN 60423
Working temperature:

static: -40℃ to +100℃, short-term: +120℃.
dynamic: -20℃ to +80℃, short-term: 100℃

Quality grade:high quality version can last 8-12 years of long service life for indoor applications & at least 5 years of long life for outdoor applications
OEM services:yes, available
Supply capability:5,000,000 pieces each month
Minimum quantity:500 pieces
Samples:free samples are available upon request
Delivery time:normally 5-8 days after confirmation of orders
Payment conditions:T/T, Western Union, L/C at sight
Shipment terms:shipped by courier like EMS / TNT / DHL / UPS / FEDEX or by sea or by air
Export packing:

100 pieces per bag + 100 pieces per color box,
special packing can be customizable as requested
































UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread

UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread 1
UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread 2
UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread 3
UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread 4
UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread 5
UV (Sunlight) Resistant Black Plastic IP68 Cable Gland M12~M75 with Elongated Metric Thread 6
